Electric and gas |
|
Certification | CE |
Rated Voltage | DC12V |
Operating Voltage Range | DC10.5V～16V |
Short-term Maximum Power Consumption | 8-10A |
Average Power Consumption | 1.8-4A |
Fuel Heat Power (W) | 2000 / 4000 / 5000 |
Fuel Consumption (g/H) | 220 / 440 / 550 |
Quiescent current | 1mA |
Warm Air Delivery Volume m3/h | 287max |
Water Tank Capacity | 10L |
Maximum Pressure of Water Pump | 2.8bar |
Maximum Pressure of System | 4.5bar |
Rated Electric Supply Voltage | ～220V/110V |
Electrical Heating Power | 900W /1800W |
Electrical Power Dissipation | 3.9A - 7.8A / 7.8A - 15.6A |
Working (Environment) Temperature | -25℃ ～ + 80℃ |
Working Altitude | ≤5000m |
Weight (Kg) | 15.6Kg（without water） |
Dimensions (mm) | 510×450×300 |
Protection level | IP21 |
Parking size | 600×485×400mm + 485×485×260mm |
G. W. | 21KG + 5.7KG |
Apply to:
Caravan, Recreational vehicles, Motor homes, Trailers, Camper vans, Trucks, Construction Vehicles, Buses, Agricultural Vehicles, Diesel Vehicles, etc.
Feature:
There are three energy options to choose from:
Gas Mode: Heater automatic adjust the power; The heater operates at the lowest power. Stop heating immediately after reaching the set temperature.
Electrical Mode: Manually select the 900W or 1800W heating mode according to the power supply capacity of the RV camp site; Manually select the 900W or 1800W heating mode according to the power supply capacity of the camp site.
Hybrid Mode: When the power demand is low (for example, maintaining the room temperature stage), the electrical heating is preferred. Until the city electricity cannot meet, the diesel heating is started, and the diesel heating function is turned off first in the power adjustment phase. In hot water working mode，gas mode or electrical mode is used to heat the tank. The tank temperature can be set to 40°C or 60°C.
