| Model | MH-B20 | MH-B30 | MH-B50 | MH-B80 | MH-C35 |
| Capacity (kg) | 200 | 300 | 500 | 800 | 350 |
| Table Length L(mm) | 700 | 852 | 852 | 920 | 920 |
| Table Width W(mm) | 450 | 502 | 502 | 520 | 520 |
| Table Min.Height Hmin(mm) | 265 | 330 | 390 | 442 | 435 |
| Table Max.Height Hmax(mm) | 755 | 910 | 910 | 1000 | 1500 |
| Handle Height h(mm) | 980 | 1100 | 1100 | 1130 | 1130 |
| Wheel Dia. (mm) | Φ100 | Φ125 | Φ125 | Φ150 | Φ150 |
| Overall Size BxC(mm) | 450x870 | 502x1050 | 520x1170 | ||
| Foot Pedal to Max.Height | ≤25 | ≤30 | ≤40 | ≤70 | ≤70 |
| Net Weight (kg) | 44 | 74 | 81 | 114 | 125 |
1.Economic and reliable.
2.New design to meet norm EN1570.
3.New hydraulic system increases safety and protects your goods, stepless rate of lowering system remains irrespective of the weight of the load.
Skid roller.
Flexible and convenient.
Safety operated.
Robust lifting mechanism.
Stainless steel AISI316 or AISI304.
Full sizes available.
High quality carbon steel.
Used in pairs or multiples.
