| Diameter (MM) | Inner Length (MM) | Width (MM) | Weight KG/M | Min. Breaking Load KN | |
| Inside min. | Outside max. | ||||
| 9.00 | 53 | 15 | 35 | 1.55 | 127 |
| 11.00 | 64 | 18 | 43 | 2.4 | 189 |
| 13.00 | 80 | 22 | 51 | 3.3 | 265 |
| 16.00 | 100 | 26 | 61 | 4.8 | 401 |
| 19.00 | 100 | 27 | 68 | 7.1 | 562 |
| 22.00 | 120 | 32 | 84 | 9.5 | 760 |
1. Super Alloy steel.
2. Finish: Black treated or painted.
3. Manufacturer's test certificate can be supplied as required.
4. 100% proof load tested and 100% calibrated.
5. Every meter is stamped with manufacturer's ID Number, Grade Number can be marked as required.
Forged super alloy steel.
25% stronger than G80.
Suitable for G100 chains.
Forged super alloy steel.
25% stronger than G80.
Suitable for G100 chains.
Alloy steel.
100% proof load tested and 100% calibrated.
Super alloy steel.
Quenched and tempered.
To suit G80 chains.
