Model | EW6000C(12V) |
Rated line pull | 6000lb (2721kg) single line |
Motor | 4.0KW/5.5HP 12V, Series Wound |
Control | Remote switch, 12ft (3.7m) lead |
Gear train | 3 Stage Planetary |
Gear reductions ratio | 218:1 |
Clutch | Sliding Ring Gear |
Braking Action | Automatic ln-The-Drum |
Drum Dimensions | φ2.5"x5.5"(φ63.5mmx140mm) |
Cable (Dia X L) | φ1/4"x66' (φ6.4mmx20m) |
Fairlead | 4-Way Roller Fairlead |
Battery | Recommended 650CCA minimum for winching |
Battery Leads | 2 gauge, 72" (1.83m) |
Overall dimensions | 17.7”x6.1"x8.6" (449.5x156x215mm) |
Mounting Bolt Pattern | 166.4mmx114.3mm |
N.W. / G.W. | 26kg / 28kg |
Apply to: Boat trailer, Warehouse, Building, Wharf, Etc.
Feature:
1.Features an all-metal planetary gear train plus mechanical and dynamic brake.
2.Free spooling clutch with ergonomic control.
3.Sealed solenoids guarantee all-weather protection.
4.Sealed handle switch and 10 feet remote.
5.Including roller fairlead and mounting plate.
