Material | Made of Mild Carbon Steel |
Head Type | Countersunk Cupped head |
Shank Type | Round Smooth Shank |
Point Type | Diamond Point |
Standard Finish | Electro-galvanized finish or Hot Dip Galvanized finish |
Standard | ASTM standard |
Packing | 50lb/carton,25lb/carton,25lb/pail,30lb/pail,20kg/carton,25kg/carton,1lb/box, 5lb/box or on customer request |
Application:
Casing nails having a small conical head, slenderer than common nail of the same length, used for laying floors, fastening match boarding, and other work in which the head may remain visible.
Feature:
Specification:
| Size | Length | Gauge | Head | Count |
| 2d | 1'' | 15½ | 12Ga | 1,090 |
| 3d | 1 1/4" | 14½ | 11Ga | 654 |
| 4d | 1 1/2" | 14 | 10Ga | 489 |
| 5d | 1 3/4" | 14 | 10Ga | 414 |
| 6d | 2'' | 12½ | 8Ga | 244 |
| 7d | 2 1/4" | 12½ | 8Ga | 215 |
| 8d | 2 1/2" | 11½ | 6 1/2Ga | 147 |
| 10d | 3'' | 10½ | 5 1/2Ga | 96 |
| 12d | 3 1/4" | 10½ | 5 1/2Ga | 88 |
| 16d | 3 1/2" | 10 | 5Ga | 74 |
| 20d | 4'' | 9 | 4Ga | 54 |
Round Smooth Shank. Diamond Point.
Smooth Shank, Ring Shank (Annular thread) or Spiral Shank. Diamond Point, Without Point or Chisel Pont.
Ring Shank. Diamond Point.
Flat head. Spiral Shank. Diamond Point.
